Rear Brake Kit – Part No: 140-9223-DR
Rear Brake Kit – Part No: 140-9223-DR
Part # 140-9223-DR
Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kit
Kit Summary:
Rear End Axle:8.8 Ford
Axle Offset:2.50
Mount Type:Radial
Caliper Type:4 - Red Powder Coat
Rotor Diameter:12.88
Min Wheel Diameter Req'd*:17*
This Brake Kit may fit 17-inch wheels. Please refer to the wheel clearance diagram to check to see if it will fit your specific wheel. Wheel Clearance Diagram
Calipers:
Left Hand - Part No:120-11782-RD
Right Hand - Part No:120-11782-RD
Type:Forged Narrow Superlite 4R
Finish Color:Red Powder Coat
Piston Count:4
Piston 1 Bore (in):1.12
Piston 2 Bore (in):1.12
Piston Area (In²):1.98
Piston Type:Stainless
Mount Type:Radial
Brake Pad Plate:7416
Brake Pad Area (In²):8.2
Brake Pad Volume (In³):3.8
Pad Compound:BP-10
Rotors:
Left Hand - Part No:160-13544-BK
Right Hand - Part No:160-13543-BK
Type:SRP Drilled Rotor
Style:SRP Drilled & Slotted
Surface Finish:Black Electro Coat
Material:Spec-37 Iron
Outside Diameter (in):12.88
Width (in):1.10
Vane Count:48 CV
Design Type:SRP-BLK
Bedded:No
Dynamically Balanced:Yes
